Home>>Solutions>>500MW and More Automatic Solar Panel Making Line

500MW and More Automatic Solar Panel Making Line solar module production line


Summary: 500MW and More Automatic Solar Panel Making Line solar module production line Including the following products: · Solar Cell Tester and Sorter · Damage Free Solar Cell Laser Cutting Machine · Solar Cell Tabber Stringer Machine · Solar String La


500MW and More Automatic Solar Panel Making Line solar module production line

Many people want to set up a solar module factory, but they still haven't started construction because they don't understand the equipment and configuration.

So, What Machines are needed about 500MW & More Automatic Solar Panel Making Line solar module production line?


500MW & More Automatic Solar Panel Making Line solar module production line Including the following products:


· Solar Cell Tester and Sorter
· Damage Free Solar Cell Laser Scribing Machine

· Solar  Cell Tabber Stringer Machine
· Solar String Lay Up Machine
· Solar Panel Bussing Machine
· Solar Module EL Defect Tester with Visual Inspecting Function
· Solar Laminator
· Solar Module Gluing &  Framing Machine

· Solar Simulator


1. Factory Layout Drawing:

500MW solar panel making line

solar module manufacturing process



Learn more about solar panel manufacturing process kindly visit :

https://www.solarmakingmachine.com/Solar-Panel-Manufacturing-Process/


2. Function & Picture of Main Machines of 500MW & More Automatic Solar Panel Making Line solar module production line:

· Solar Cell Tester and Sorter

Function:

Solar cell tester and Sorter is used to test the electrical performance of Mono-Si or Poly-Si solar cell pieces and record the results in files.

Picture:

solar cell tester and sortersolar cell tester


· Damage Free Solar Cell Laser Scribing Machine

Function:

Damage free solar cell laser scribing machine is used to cut solar cell into half piece or 1/3 piecewhich can increase the output of the solar panel power.

Damage free solar cell laser scribing machine is with lower power, lower temperature, and water-free dicing, and also has higher bending strength, better electrical performance, and no secondary pollution or water-caused micro-broken after cutting.

Picture:

Damage Free Solar Cell Laser Scribing MachineSolar Cell Laser Scribing Machine


· Solar  Cell Tabber Stringer Machine

Function:

Automatic solar cell tabber stringer machine is used to weld the solar cells one by one through copper ribbon, and the cells are connected in series to form a string. The entire welding process is fully automated.

Picture:

tabber and stringer machine pricetabber and stringer machine


· Solar String Lay Up Machine

Function:

Used to achieving solar string automatic laying on glass EVA, and transporting module to the next process

Solar String Lay Up MachineSolar Cell Lay Up Machine


· Solar Panel Bussing Machine

Function:

Adopt the method of separating the cell string from the glass, and grab the cell string in the air, then to interconnected solder the head, middle and tail bus bar of the middle wire edition module at a certain height; It has the function of a roll feeding bus bar, bending U and L leads upwards.

solar panel bussing machinesolar soldering bussing machine


· Solar Module EL Defect Tester with Visual Inspecting Function

Function:

Automatic solar module EL defect tester with visual inspecting function is used in testing the solar cell crack,breakage, black spot,mixed wafers,process defect,cold solder joint phenomenon.

Picture:

Solar Module EL Defect Tester with Visual Inspecting FunctionSolar Module EL Defect Tester


· Solar Laminator

Function:

Solar  laminator is a mechanical device that presses multiple layers of materials together.

Picture:

solar laminatorSolar Panel Laminator

· Solar Module Gluing &  Framing Machine

Function:

Automatic gluing & framing machine is used to install the aluminum frame and automatically overflow glue.

Picture:

Solar Module Gluing & Framing Machinesolar framing machine

· Solar Simulator

Function:

Automatic solar Simulator is used to test the electric performance of Mono-Si or Poly-Si solar modules and record the results in files .

Picture:

solar simulatorsolar panel tester



3. Packaging and transportation of 500MW & More Automatic Solar Panel Making Line solar module production line


4. Case of 500MW & More Automatic Solar Panel Making Line solar module production line
